Product Overview
ACCuMeasure™ 9000 —
Monitor the health of power systems effectively.
Accurately capture, analyze, and visualize key electrical parameters to ensure reliable, efficient, and stable power distribution.
Technical Specifications
- Voltage Input: 50–600V AC
- Current Input: 10mA – 6A
- Frequency Range: 45–65 Hz
- Sampling Rate: 512 samples per cycle
- Accuracy Class: Class 1.0 (IEC 62053-21), optional Class 0.2S
- Harmonics: THD + individual harmonics up to 63rd order
- Data Storage: 256 MB internal memory, USB logging up to 8GB
- Communication: RS485 (Modbus)
- Power Quality Detection: Dip/Swell, interruptions, unbalance, crest factor, K-factor (EN 50160)
- Operating Conditions: -10°C to +55°C, 5–95% humidity, CAT III
- Protection: IP54 (front), IP20 (terminals)
- Weight: 600 g
Benefits
☑ Industrial-Rated Design
☑ Comprehensive Electrical Parameter Monitoring
☑ Integrated Data Logging
☑ Modbus Communication Ready
Power monitoring platform
Power monitoring platform supporting voltage, current, energy, demand, and frequency measurements.
512 samples-per-cycle acquisition rate
512 samples-per-cycle acquisition rates for electrical events and disturbance analysis.
Harmonic monitoring
Harmonic monitoring through the 63rd order with THD, unbalance, crest factor, and K-factor calculations.
Built-in 256 MB memory
Built-in 256 MB memory with USB logging capability up to 8 GB.
Seamless Integration
RS485 Modbus RTU communications for seamless integration into monitoring and control systems.
Industrial-grade CAT III meter
Industrial-grade CAT III meter designed for commercial and industrial power distribution applications.
